high precision metal slant bed CNC Lathe

  • high precision metal slant bed CNC Lathe
  • high precision metal slant bed CNC Lathe
  • high precision metal slant bed CNC Lathe
  • high precision metal slant bed CNC Lathe

high precision metal slant bed CNC Lathe

    Packaging: protective film package,if necessary we could packed as customs*s request.
    Productivity: 20 sets /month
    Brand: DML
    Transportation: Ocean
    Place of Origin: china
    Supply Ability: 20 sets /month
    Certificate: ISO
    HS Code: 8458190000
    Port: shanghai,ningbo,qingdao

Basic Info

Model No.: CNC46

Product Description

1. High precision Slant Bed CNC Lathe with Taiwan screw & linear guideway.
2.
Metal Lathe Machine with High precision cartridge type spindle ensure the rigidity and precision of metal CNC Lathe.
3. slant bed machine with high precision C3 grade ball screw ensure positioning accuracy more stable.
4. Siemens, Fanuc, GSK, controller can be choice.
5. Monoblock cast iron of the whole machine ensure high rigidity.
6. China metal 45 degree stand bed CNC Lathe with tailstock.


20210916135214



Slant Bed Lathe Machine Features
Higher stability one-piece machine bed
3-gear spindle speed,step-less in gear
Metal Lathe machine with Higher rigidity pedestal
Universal Lathe with Wider layer board
Integrated automatic lubrication system

C1C2

C3Application1

Standard Accessories:

1.System: GSK

2.3-jaw manual chuck

3.4-station electric turret

4.Frequency spindle motor

5.Stepless speed changer

6.Manual tailstock

7.Lighting system

8.Cooling system



slant bed Lathe machine parameters :

Model

CK30L

CK32L

CK36L

Max. swing oner bed

φ300mm

φ320mm

φ360mm

Max. swing over carriage

φ140mm

φ180mm

φ210mm

Max. cutting legth

350mm

450mm

500/750mm

Rail width

260mm

284mm

284mm

Spindle nose

A2-4

A2-5

A2-5,A2-6

Spindle bore

φ46mm

φ56mm

φ56mm,(62mm)

Taper of spindle bore

1:20

1:20

1:20

Chuck

5"

6"

6" , ( 8")

Range of spindle speed

150-6000rpm

150-4200rpm

150-4200rpm

X axis travel

150mm

190mm

210mm

Z axis travel

350mm

450/650mm

500/750mm

X/Z rapid speed

20/20m/min

20/20m/min

20/20m/min

Hydraulic turret

8

8

8

Max. section of tool

16*16mm

20*20mm

20*20mm

Stroke of tailstock sleeve

60mm

80mm

80mm

Diameter/ Hole of tailstock sleeve

φ40mm/MT3

φ60mm/MT4

φ60mm/MT4

Main motor power

4KW

4KW/5.5KW

5.5KW/7.5KW

Coolant pump power

370W

370W

370W

Overall dimensions L*W*H

1800*1250*1550mm

2300*1550*1750mm

2630/2910*1550*1750mm

Packing size L*W*H

2000*1400*1750mm

2500*1750*2000mm

2830/3130*1750*2150mm

N.W/G.W

1750KG/2000KG

2200KG/2600KG

2700KG/3000KG

20210916151731

slant bed Lathe machine Application
These slant bed lathe machines are suitable for turning internal and external cylindrical,Conical and other swing surfaces as well as various metric,lnch,module and diametric pitch threads.metal lathe lathe can also be used for broaching oil grooves and keyways.

This slant bed lathe machine is mainly used for processing various shafts, disk parts, turning can be all kinds of screw thread, arc, cone and plane of internal and external surface can satisfy the ferrous and non-ferrous metals the speed requirement of high-speed chip. Suitable for cars, motorcycles, electronics, aerospace, military industry and other industries to high efficiency, large quantity and high precision of parts processing.


20210916143500



We also deal in other products:high speed Hydraulic ironworker,quality Shearing machine,,high speed Plasma cutting machine,Cnc Laser Cutting Machine, Hydraulic Press Brake Machine.Hydraulic press machine,Pipe punching machine and so on .A variety of choices to make your work easier and faster




Jingjiang lifeng machine tool manufacturing CO.,ltd

  • 1
  • 2
  • 3
  • 4
  • 5
 Lifeng company is a mature brand in CHINA,through our many years research in technology,our design including structure and detailed security and precision has enhanced greatly,and can match all the CE standard or more strict standard.Our machines distribute worldwide to about 50 countries where there are metal plate industry ,there are Brillante machines.And where there are our machines,there are good reputation and terminal user satisfaction.
